Sep 1, 2019 / EXERCISE, PROGRAMMING, STYLE

Exercises in Programming Style: sharing data among threads

Last week, we solved the word count problem using the Actor model: objects running on different threads and communicating through messages. This week, we will drop objects, and use data structures that are shared among the threads: such a shared structure is called data space in the book.

This is the 17^th post in the Exercises in Programming Style focus series.Other posts include:

Modelling the data space

The original Python code uses two dedicated data spaces:

To store the words read from the source file,
To store the word frequencies

The Python code uses queues to model the data spaces. Hence, it makes sense to do the same in Kotlin. However, the Java API offers lots of choices, as this abridged diagram shows:

Let’s describe the queue and the blocking queue.

Queue

In Java, the Queue interface has no definite semantics regardering the ordering of elements: it can be FIFO, LIFO or something completely different, such as based on a priority attribute.

Queues offer two different ways to add, check and remove elements: one throws an exception if the operation fails, the other returns a specific value. For example, removing an element might fail if the queue is empty.

Feature Exception Special value

Feature	Exception	Special value
Checks an element	`element(): E`	`peek(): E`
Adds an element	`add(e: E): boolean`	`offer(e: E): boolean`
Removes an element	`remove(e: E): boolean`	`poll(e: E): boolean`

Checks an element

element(): E

peek(): E

Adds an element

add(e: E): boolean

offer(e: E): boolean

Removes an element

remove(e: E): boolean

poll(e: E): boolean

BlockingQueue

A blocking queue is:

A Queue that additionally supports operations that wait for the queue to become non-empty when retrieving an element, and wait for space to become available in the queue when storing an element.

— JavaDoc
https://docs.oracle.com/javase/7/docs/api/java/util/concurrent/BlockingQueue.html

It adds two different ways to achieve the above operations: a blocking one and one with timeout.

Feature Blocking Timeout

Feature	Blocking	Timeout
Adds	`put(e: E): boolean`	`offer(e: E, long timeout, TimeUnit unit): boolean`
Removes	`take(): E`	`poll(long timeout, TimeUnit unit): E`

Adds

put(e: E): boolean

offer(e: E, long timeout, TimeUnit unit): boolean

Removes

take(): E

poll(long timeout, TimeUnit unit): E

There are two out-of-the-box implementations of blocking queue of interest:

ArrayBlockingQueue backed by a simple array
LinkedBlockingQueue using nodes linked together

Porting the Python code

The straightforward porting of the original Python code relies on the same design: mutable data structures and timeout.

The implementation of the main function goes like this:

fun run(filename: String): Map<String, Int> {
    val freqSpace = LinkedBlockingQueue<Map<String, Int>>()
    val wordSpace = read(filename)
        .flatMap { it.toLowerCase().split("\\W|_".toRegex()) }
        .filter { it.isNotBlank() && it.length >= 2 }
        .toBlockingQueue()
    val count = 4
    val executorService = Executors.newFixedThreadPool(count)
    val callables = IntRange(1, 4).map { _ ->
        { processWords(wordSpace, freqSpace) }                   (1)
    }.map { Executors.callable(it) }                             (2)
    executorService.invokeAll(callables)                         (3)
    val frequencies = mutableMapOf<String, Int>()                (4)
    while (freqSpace.isNotEmpty()) {                             (5)
        val partial = freqSpace.poll(1, TimeUnit.SECONDS)        (5) (6)
        partial?.entries?.forEach {                              (5)
            frequencies.merge(it.key, it.value) {                (5)
              count, value -> count + value                      (5)
            }
        }
    }
    return frequencies
        .toList()
        .sortedByDescending { it.second }
        .take(25)
        .toMap()
}

fun <E> List<E>.toBlockingQueue() = LinkedBlockingDeque<E>(this)

1	Wrap the `processWord()` function in a lambda
2	Transform a `Callable`-compatible lambda to a `Runnable`
3	Start to run the threads, waiting for the last one to finish
4	Mutable map to store the final results
5	Empty the queue and collect results in the map
6	Remove elements from the queue using the timeout flavor

fun processWords(words: BlockingQueue<String>,
                 frequencies: BlockingQueue<Map<String, Int>>) {
  val stopWords = read("stop_words.txt")
    .flatMap { it.split(",") }
  val wordFreq = mutableMapOf<String, Int>()
  while (words.isNotEmpty()) {                                   (1)
    val word = words.poll(1, TimeUnit.SECONDS)                   (1) (2)
    if (word != null && !stopWords.contains(word))               (1)
      wordFreq.merge(word, 1) {                                  (1)
        count, value -> count + value                            (1)
      }
  }
  frequencies.put(wordFreq)
}

1	As above, empty the queue and collect the results in a map
2	Likewise, remove elements using a timeout

Introducing concurrent hash maps

The above code, just as the original Python solution, has an issue: it uses a queue to store maps of partial word frequencies. Then, those partial results need to be combined together to get the final word frequencies. Why not compute the count in each thread?

We need a thread-safe map: for this, the Java API offers the concurrent hash map. It offers or overrides methods that are thread-safe.

With concurrent hash maps, the processWords() function can be updated to:

fun processWords(words: BlockingQueue<String>,
                 frequencies: ConcurrentMap<String, Int>) {
  val stopWords = read("stop_words.txt")
    .flatMap { it.split(",") }
  while (words.isNotEmpty()) {
    val word = words.poll(1, TimeUnit.SECONDS)
    if (word != null && !stopWords.contains(word))
      frequencies.merge(word, 1) {
        count, value -> count + value
      }
  }
}

Since frequencies are now combined in the previous function, the run() function can be simplified:

val executorService = Executors.newFixedThreadPool(count)
val callables = IntRange(1, 4).map { _ ->
  { processWords(wordSpace, freqSpace) }
}.map { Executors.callable(it) }
executorService.invokeAll(callables)
return freqSpace
  .toList()
  .sortedByDescending { it.second }
  .take(25)
  .toMap()

Sharing data among threads requires to synchronize thread access. In turn, this requires locks and impacts performances. Concurrency experts now this: the best way to avoid concurrency issues is to avoid working on shared data when possible. In our case, the words space is shared among all threads for no good reason.

To avoid locks, we could split the words into lists, and send a list to a each thread to be processed separately:

val count = 4
val callables = words.chunked(words.size / count)           (1)
  .map { Runnable { processWords(it, freqSpace) }}          (2)
  .map { Executors.callable(it) }                           (3)
val executorService = Executors.newFixedThreadPool(count)   (3)
executorService.invokeAll(callables)                        (3)

1	Create chunks of nearly-equivalent size out of the overall words list
2	Map each chunk to a `Runnable`. Note that explicitly assigning the lambda to a `Runnable` is not strictly necessary, it improves readability
3	The rest of the code is as before

Conclusion

Concurrent code is hard to write, hard to reason about, and bugs are more likely to occur. Java provides thread-safe dedicated data structures to lessen the burden, even a bit.

Finally, the best way to completely avoid those issues is to completely avoid sharing data. Be sure to have that as your fist option when possible.

The complete source code for this post can be found on Github.
